I’m trying to make a model rotate 90 degrees on a certain axis once it’s clicked. I wrote this code but I’m getting a lot of errors I can’t understand that are apparently syntax issues.
Assets/Scripts/Angeler.cs(28,29): error CS1525: Unexpected symbol case1', expecting }‘, case', or default:’
Assets/Scripts/Angeler.cs(34,45): error CS1525: Unexpected symbol while' Assets/Scripts/Angeler.cs(38,30): error CS1519: Unexpected symbol :’ in class, struct, or interface member declaration
Assets/Scripts/Angeler.cs(38,40): error CS1519: Unexpected symbol ==' in class, struct, or interface member declaration Assets/Scripts/Angeler.cs(39,55): error CS1519: Unexpected symbol <’ in class, struct, or interface member declaration
Assets/Scripts/Angeler.cs(41,57): error CS1519: Unexpected symbol (' in class, struct, or interface member declaration Assets/Scripts/Angeler.cs(41,77): error CS1519: Unexpected symbol ,’ in class, struct, or interface member declaration
Assets/Scripts/Angeler.cs(43,30): error CS8025: Parsing error
using UnityEngine;
using System.Collections;
public class Angeler : MonoBehaviour {
private float anglex;
private bool IsSpinning;
// Use this for initialization
void Start () {
anglex = transform.eulerAngles.x; //anglex is the rotation value of x
print(anglex);
}
void OnMouseDown()
{
if (transform.rotation.eulerAngles [0] % 90 == 0) { //so the player won't be able to click while the cube is spinning
IsSpinning = true;
} else {
IsSpinning = false;
}
}
void Update () {
if (IsSpinning)
{
switch (anglex)
{
case1: anglex == 0
while (anglex < 90) //every click will rotate 90 degrees
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
case2: anglex == 90
while (anglex < 180)
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
case3: anglex == 180
while (anglex < 270)
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
case4: anglex == 270
while (anglex < 360)
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
}
}
if (anglex == 360)
{
anglex = 0; // restarting the sequence after the model completely spins 360.
}
}
}
The case statements are wrong. It should be along the lines of:
switch (anglex)
{
case 90:
//do something here
break;
case 180:
//do something else
break;
}
have a look at:
1 Like
Problem is that “switch” does not accept floats :-/
I tried the various ways of converting floats to int but no success. Any ideas? Or should I redo the code and avoid switch?
to be honest, i think setting up a coroutine that will rotate the gameobject by 90 degrees from the initial starting rotation would be a better approach, it then wouldn’t care what the starting rotation was and would not need to check each case…
Well, maybe, but my code should work right? I changed the “switch” to if, if else statements…and every time I click on my object Unity freezes and I have to Clt+Alt+Del to end process. Why would it freeze?
using UnityEngine;
using System.Collections;
public class Angeler : MonoBehaviour {
private float anglex;
private bool IsSpinning;
// Use this for initialization
void Start () {
anglex = transform.eulerAngles.x; //anglex is the rotation value of x
print(anglex);
}
void OnMouseDown()
{
if (transform.rotation.eulerAngles [0] % 90 == 0) { //so the player won't be able to click while the cube is spinning
IsSpinning = true;
} else {
IsSpinning = false;
}
}
void Update () {
if (IsSpinning)
{
if (anglex == 0)
{
while (anglex < 90) //every click will rotate 90 degrees
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
}
else if (anglex == 90)
{
while (anglex < 180)
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
}
else if (anglex == 180)
{
while (anglex < 270)
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
}
else if (anglex == 270)
{
while (anglex < 360)
{
transform.Rotate(30 * Time.deltaTime, 0, 0);
}
}
}
if (anglex == 360)
{
anglex = 0; // restarting the sequence after the model completely spins 360.
}
}
}
you never update angleX… so while(anglex < xx) will infinite loop.
Your code is running within Update() you don’t need to use while’s
OK, noted. Now it almost works. It rotates 90 degrees when I click, but then I strangely have to click it 10 times to make it spin again and it rotates BACKWARDS until it reaches 270 degrees. WTF?
I want it to rotates 90 degrees positively every click.
using UnityEngine;
using System.Collections;
public class Angeler : MonoBehaviour {
private float anglex;
private bool IsSpinning;
// Use this for initialization
void Start () {
anglex = transform.eulerAngles.x; //anglex is the rotation value of x
print(anglex);
IsSpinning = true;
}
void OnMouseDown()
{
anglex++;
Debug.Log ("YO!");
IsSpinning = true;
}
void Update () {
anglex = transform.eulerAngles.x; //anglex is the rotation value of x
if (IsSpinning == true) {
if (anglex < 90) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
} else if (anglex <= 180 && anglex >= 90) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
} else if (anglex <= 270 && anglex >= 180) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
} else if (anglex <= 360 && anglex >= 270) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
}
if (anglex == 0) {
IsSpinning = false;
} else if (anglex == 90) {
IsSpinning = false;
} else if (anglex == 180){
IsSpinning = false;
}
} else if (anglex == 270) {
IsSpinning = false;
}
else if (anglex == 360)
{
anglex = 0; // restarting the sequence after the model completely spins 360.
IsSpinning = false;
}
Debug.Log (anglex);
Debug.Log (IsSpinning);
}
}
You’re making this way too hard on yourself mate. Use Mathf.MoveTowards() and simplify that big mess you have:
public class Angeler : MonoBehaviour
{
private float currentRoation;
private float targetRotation;
void Start()
{
currentRotation = transform.eulerAngles.x;
targetRotation = transform.eulerAngles.x;
}
void OnMouseDown()
{
if(currentRotation == targetRotation)
{
targetRotation += 90;
}
}
void Update()
{
currentRotation = Mathf.MoveTowards(currentRotation, targetRotation, 30 * Time.deltaTime);
transform.rotation = Quaternion.Euler(currentRotation, transform.eulerAngles.y, transform.eulerAngles.z);
}
}
First off, thank you, but your code is also buggy. The cube jitters and glitches while it spins the second time and it strangely double-rotates after a single clicks. Going from 0 to 90 back to 0 and back to 90 then it stops, then if you click on it again it starts glitching.
I realize that my code is not the right way to do things. But theoretically, it should work right? Why doesn’t it work?
@GroZZleR he’s right, it goes a little glitchy once it’s past 90, current rotation/target rotation look fine but it looks like the euler <> quaternion conversion is flipping the y/z by 180.
@Valda_Vaux
if (anglex < 90) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
} else if (anglex <= 180 && anglex >= 90) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
} else if (anglex <= 270 && anglex >= 180) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
} else if (anglex <= 360 && anglex >= 270) {
transform.Rotate (30 * Time.deltaTime, 0, 0);
}
this section is completely redundant… all of the if conditions overlap and the action to be taken is the same. Need to rethink the logic here.
if(anglex ==0){...
anglex is a float, it’s very unlikely it’s going to be exactly 0, rather 0.00000001 etc.
In general I’d agree with Groz and say it looks over-engineered.
I understand that and that’s why I changed the code to be
if (anglex > 0 && anglex < 1)
if (anglex > 89 && anglex < 91)
…
still the same thing happens. I do not intend for this to be the code for my game, I just want to know “why” it’s not working. I treat it as a learning experience.
PS I’m not a “he” I’m a “she”
My apologies for the bad code. Quaternion.RotateTowards works flawlessly from what I can see:
public class CubeRotator : MonoBehaviour
{
private Quaternion currentRotation;
private Quaternion targetRotation;
void Start()
{
currentRotation = transform.rotation;
targetRotation = transform.rotation;
}
void OnMouseDown()
{
if (currentRotation == targetRotation)
{
targetRotation *= Quaternion.Euler(90.0f, 0.0f, 0.0f);
}
}
void Update()
{
currentRotation = Quaternion.RotateTowards(transform.rotation, targetRotation, 30.0f * Time.deltaTime);
transform.rotation = currentRotation;
}
}
1 Like
First off, thank you.
Secondly, I still don’t understand something… here are the start rotation positions:
X: 0 Y: 0 Z: 0
First Click
X: 90 Y: 0 Z: 0
Second Click
X: 0 Y: 180 Z: 180
Third Click:
X: 270 Y: 0 Z: 0
Forth Click:
X: 0 Y: 0 Z: 0
Why do the Y and Z change if target rotation only indicates 90 degrees on X rotational axis?
