I’m struggling to find a way to do the following:
There are two entities. B is a child of A. A is bound to rotate with mouse movement. B SHOULD “stay upright in the world”.
I think what I need is to do a quaternion rotation from B’s up to “absolute world up, at B’s localToWorld.Position”.
Here’s a reference video to what I’m trying accomplish, but with ECS:
Thanks a ton in advance, for anyone that’s able to help!
Here is how you create a billboard system:
using UnityEngine;
using Unity.Entities;
using Unity.Mathematics;
using Unity.Transforms;
public class BillboardAuthoring : MonoBehaviour
{
[SerializeField] EMode _mode = EMode.YAxis;
#if UNITY_EDITOR
void OnDrawGizmos ()
{
UnityEditor.Handles.Label( transform.position , _mode.ToString() );
}
#endif
public class Baker : Baker<BillboardAuthoring>
{
public override void Bake ( BillboardAuthoring authoring )
{
Entity entity = this.GetEntity( authoring , TransformUsageFlags.WorldSpace );
if( authoring._mode==EMode.Basic ) AddComponent<IsBasicBillboard>( entity );
else if( authoring._mode==EMode.YAxis ) AddComponent<IsYAxisBillboard>( entity );
}
}
public enum EMode : byte
{
Basic , YAxis
}
}
[UpdateInGroup( typeof(PresentationSystemGroup) )]
[WorldSystemFilter( WorldSystemFilterFlags.Default | WorldSystemFilterFlags.Editor )]
[RequireMatchingQueriesForUpdate]
public partial struct BillboardBasicSystem : ISystem
{
public void OnUpdate ( ref SystemState state )
{
Camera cam = Camera.main;
if( cam==null ) return;
Transform cameraTransform = cam.transform;
float4x4 ltw = cameraTransform.localToWorldMatrix;
new Job{
C0 = ltw.c0 ,
C1 = ltw.c1 ,
C2 = ltw.c2 ,
}.ScheduleParallel();
}
[WithAll( typeof(IsBasicBillboard) )]
[Unity.Burst.BurstCompile]
public partial struct Job : IJobEntity
{
public float4 C0, C1, C2;
void Execute ( ref LocalToWorld transform )
{
transform.Value.c0 = C0;
transform.Value.c1 = C1;
transform.Value.c2 = C2;
}
}
}
[UpdateInGroup( typeof(PresentationSystemGroup) )]
[WorldSystemFilter( WorldSystemFilterFlags.Default | WorldSystemFilterFlags.Editor )]
[RequireMatchingQueriesForUpdate]
public partial struct BillboardYAxisSystem : ISystem
{
public void OnUpdate ( ref SystemState state )
{
Camera cam = Camera.main;
if( cam==null ) return;
new Job{
CameraPosition = cam.transform.position ,
}.ScheduleParallel();
}
[WithAll( typeof(IsYAxisBillboard) )]
[Unity.Burst.BurstCompile]
public partial struct Job : IJobEntity
{
public float3 CameraPosition;
void Execute ( ref LocalToWorld transform )
{
// z
float3 position = transform.Position;
float3 target = new float3( CameraPosition.x , position.y , CameraPosition.z );
float zscale = math.length( transform.Value.c2 );
float3 z = -math.normalize(target-position);
transform.Value.c2 = new float4( z * zscale , 0 );
// y
float yscale = math.length( transform.Value.c1 );
transform.Value.c1 = new float4(0,yscale,0,0);
// x
float3 x = new float3( transform.Value.c0.x , transform.Value.c0.y , transform.Value.c0.z );
float xscale = math.length( transform.Value.c0 );
transform.Value.c0 = new float4( math.cross(z,new float3(0,1,0)) * xscale , 0 );
}
}
}
public struct IsBasicBillboard : IComponentData {}
public struct IsYAxisBillboard : IComponentData {}
Let GPU do this work via vertex shader. ECS/Burst are cool but no CPU involvement is almost always better
.
{
"m_SGVersion": 3,
"m_Type": "UnityEditor.ShaderGraph.GraphData",
"m_ObjectId": "80cb4d329af2482aaa63ce452eaae22f",
"m_Properties": [
{
"m_Id": "85672431213548ca8a0ef8bc5f543d8c"
}
],
"m_Keywords": [],
"m_Dropdowns": [],
"m_CategoryData": [
{
"m_Id": "4297c401299a4f48a401d53ed3a76471"
}
],
"m_Nodes": [
{
"m_Id": "635f8317c1d6444c963b9d6e621b45b9"
},
{
"m_Id": "6e737174c3bc48a893525e11d8b94eb6"
},
{
"m_Id": "063559dd18bb40949fba96df86db5c17"
},
{
"m_Id": "231b4bcce88249ea9294317ac9f620d1"
},
{
"m_Id": "92c17bcc8b8c425c9582a5c1a1fe81e8"
},
{
"m_Id": "37375e12bf3c41eb91c35e09b4e7946f"
},
{
"m_Id": "e32470a4c1ba4209826e24682298701c"
},
{
"m_Id": "bdc0ea7eb9cb447d8dd08fcfbcd34555"
},
{
"m_Id": "325e4f19c5294b69a36f11265d8641b9"
},
{
"m_Id": "2662bd3f11554d08aaccba49bd287b99"
},
{
"m_Id": "eb63323c6b5d49feacc5978986facc6f"
},
{
"m_Id": "35fc4044314442a584349e8789db0747"
},
{
"m_Id": "277efdbd13144e5daf3a0752b8581470"
},
{
"m_Id": "d31479c4d4c64b049755104be6939c44"
},
{
"m_Id": "5a76b4302dec45ddb2190ecc57c281d9"
},
{
"m_Id": "e01343c4cdb845dcb252212877f70ee4"
},
{
"m_Id": "cf8ac88182a54394afb4615ded88792e"
},
{
"m_Id": "6404d7bbf8624faf931ba1471844502d"
}
],
"m_GroupDatas": [],
"m_StickyNoteDatas": [],
"m_Edges": [
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "2662bd3f11554d08aaccba49bd287b99"
},
"m_SlotId": 1
},
"m_InputSlot": {
"m_Node": {
"m_Id": "eb63323c6b5d49feacc5978986facc6f"
},
"m_SlotId": 1
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "277efdbd13144e5daf3a0752b8581470"
},
"m_SlotId": 0
},
"m_InputSlot": {
"m_Node": {
"m_Id": "d31479c4d4c64b049755104be6939c44"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "325e4f19c5294b69a36f11265d8641b9"
},
"m_SlotId": 0
},
"m_InputSlot": {
"m_Node": {
"m_Id": "5a76b4302dec45ddb2190ecc57c281d9"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "35fc4044314442a584349e8789db0747"
},
"m_SlotId": 3
},
"m_InputSlot": {
"m_Node": {
"m_Id": "635f8317c1d6444c963b9d6e621b45b9"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "37375e12bf3c41eb91c35e09b4e7946f"
},
"m_SlotId": 1
},
"m_InputSlot": {
"m_Node": {
"m_Id": "e32470a4c1ba4209826e24682298701c"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "5a76b4302dec45ddb2190ecc57c281d9"
},
"m_SlotId": 2
},
"m_InputSlot": {
"m_Node": {
"m_Id": "eb63323c6b5d49feacc5978986facc6f"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "6404d7bbf8624faf931ba1471844502d"
},
"m_SlotId": 0
},
"m_InputSlot": {
"m_Node": {
"m_Id": "231b4bcce88249ea9294317ac9f620d1"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "6404d7bbf8624faf931ba1471844502d"
},
"m_SlotId": 7
},
"m_InputSlot": {
"m_Node": {
"m_Id": "e01343c4cdb845dcb252212877f70ee4"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "92c17bcc8b8c425c9582a5c1a1fe81e8"
},
"m_SlotId": 1
},
"m_InputSlot": {
"m_Node": {
"m_Id": "37375e12bf3c41eb91c35e09b4e7946f"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "bdc0ea7eb9cb447d8dd08fcfbcd34555"
},
"m_SlotId": 2
},
"m_InputSlot": {
"m_Node": {
"m_Id": "35fc4044314442a584349e8789db0747"
},
"m_SlotId": 2
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "bdc0ea7eb9cb447d8dd08fcfbcd34555"
},
"m_SlotId": 2
},
"m_InputSlot": {
"m_Node": {
"m_Id": "d31479c4d4c64b049755104be6939c44"
},
"m_SlotId": 2
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "cf8ac88182a54394afb4615ded88792e"
},
"m_SlotId": 0
},
"m_InputSlot": {
"m_Node": {
"m_Id": "6404d7bbf8624faf931ba1471844502d"
},
"m_SlotId": 1
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "d31479c4d4c64b049755104be6939c44"
},
"m_SlotId": 3
},
"m_InputSlot": {
"m_Node": {
"m_Id": "6e737174c3bc48a893525e11d8b94eb6"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "e32470a4c1ba4209826e24682298701c"
},
"m_SlotId": 1
},
"m_InputSlot": {
"m_Node": {
"m_Id": "bdc0ea7eb9cb447d8dd08fcfbcd34555"
},
"m_SlotId": 0
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "e32470a4c1ba4209826e24682298701c"
},
"m_SlotId": 3
},
"m_InputSlot": {
"m_Node": {
"m_Id": "bdc0ea7eb9cb447d8dd08fcfbcd34555"
},
"m_SlotId": 1
}
},
{
"m_OutputSlot": {
"m_Node": {
"m_Id": "eb63323c6b5d49feacc5978986facc6f"
},
"m_SlotId": 2
},
"m_InputSlot": {
"m_Node": {
"m_Id": "35fc4044314442a584349e8789db0747"
},
"m_SlotId": 0
}
}
],
"m_VertexContext": {
"m_Position": {
"x": 0.0,
"y": 0.0
},
"m_Blocks": [
{
"m_Id": "635f8317c1d6444c963b9d6e621b45b9"
},
{
"m_Id": "6e737174c3bc48a893525e11d8b94eb6"
},
{
"m_Id": "063559dd18bb40949fba96df86db5c17"
}
]
},
"m_FragmentContext": {
"m_Position": {
"x": -0.00002384185791015625,
"y": 532.0
},
"m_Blocks": [
{
"m_Id": "231b4bcce88249ea9294317ac9f620d1"
},
{
"m_Id": "e01343c4cdb845dcb252212877f70ee4"
}
]
},
"m_PreviewData": {
"serializedMesh": {
"m_SerializedMesh": "{\"mesh\":{\"instanceID\":0}}",
"m_Guid": ""
},
"preventRotation": false
},
"m_Path": "Shader Graphs",
"m_GraphPrecision": 1,
"m_PreviewMode": 2,
"m_OutputNode": {
"m_Id": ""
},
"m_SubDatas": [],
"m_ActiveTargets": [
{
"m_Id": "c548ef7607014e0da7a8e20ba3e418e9"
}
]
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "02ffabbb5d2540c9978d43fe9bced66e",
"m_Id": 4,
"m_DisplayName": "Far Plane",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Far Plane",
"m_StageCapability": 3,
"m_Value": 1.0,
"m_DefaultValue": 1.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.BlockNode",
"m_ObjectId": "063559dd18bb40949fba96df86db5c17",
"m_Group": {
"m_Id": ""
},
"m_Name": "VertexDescription.Tangent",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": 0.0,
"y": 0.0,
"width": 0.0,
"height": 0.0
}
},
"m_Slots": [
{
"m_Id": "ef119d9737b248aab2997c014c8e18bc"
}
],
"synonyms": [],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_SerializedDescriptor": "VertexDescription.Tangent"
}
{
"m_SGVersion": 2,
"m_Type": "UnityEditor.Rendering.Universal.ShaderGraph.UniversalUnlitSubTarget",
"m_ObjectId": "081930db40d3417eaa49d6e6df667383"
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "11c6a4fd998645218cee336bbfcb2edc",
"m_Id": 0,
"m_DisplayName": "In",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "In",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "16afa4add64447f799abb5bd6004fb55",
"m_Id": 5,
"m_DisplayName": "Z Buffer Sign",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Z Buffer Sign",
"m_StageCapability": 3,
"m_Value": 1.0,
"m_DefaultValue": 1.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "16b9357b55494da0b1940bd5d5e57936",
"m_Id": 2,
"m_DisplayName": "World Bounds Min",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "World Bounds Min",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "17234cae634b4599bc55b9e1f568a9e0",
"m_Id": 0,
"m_DisplayName": "In",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "In",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "21821b9616e445458615181a9341aa56",
"m_Id": 2,
"m_DisplayName": "Rotation",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Rotation",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.BlockNode",
"m_ObjectId": "231b4bcce88249ea9294317ac9f620d1",
"m_Group": {
"m_Id": ""
},
"m_Name": "SurfaceDescription.BaseColor",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": 0.0,
"y": 0.0,
"width": 0.0,
"height": 0.0
}
},
"m_Slots": [
{
"m_Id": "597474c07860476ebfc4d50be1b31f22"
}
],
"synonyms": [],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_SerializedDescriptor": "SurfaceDescription.BaseColor"
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.ObjectNode",
"m_ObjectId": "2662bd3f11554d08aaccba49bd287b99",
"m_Group": {
"m_Id": ""
},
"m_Name": "Object",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -702.0,
"y": -201.0,
"width": 153.0,
"height": 173.0
}
},
"m_Slots": [
{
"m_Id": "e4341a2a112347e89e6a8a1a1f722075"
},
{
"m_Id": "807fca3843a848d4bf68ecd40375fe7b"
},
{
"m_Id": "16b9357b55494da0b1940bd5d5e57936"
},
{
"m_Id": "ca2f6195da984047a45d29dd06c85252"
},
{
"m_Id": "835e2be9954a4ec284e3a00899f98e0f"
}
],
"synonyms": [
"position",
"scale",
"bounds",
"size"
],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.NormalVectorNode",
"m_ObjectId": "277efdbd13144e5daf3a0752b8581470",
"m_Group": {
"m_Id": ""
},
"m_Name": "Normal Vector",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -598.0,
"y": 156.0,
"width": 206.0,
"height": 131.0
}
},
"m_Slots": [
{
"m_Id": "73db6d308de348e69080623523c9292a"
}
],
"synonyms": [
"surface direction"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 2,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_Space": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "2b00144db2ef47df8765e2d9ec197ab4",
"m_Id": 6,
"m_DisplayName": "B",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "B",
"m_StageCapability": 2,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "2b0e6acb90c543a5b15de86a021447af",
"m_Id": 2,
"m_DisplayName": "Orthographic",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Orthographic",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "2da8c8085d9b4bcc8ddcfb7e64076d8c",
"m_Id": 4,
"m_DisplayName": "A",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "A",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 1,
"m_Type": "UnityEditor.ShaderGraph.PositionNode",
"m_ObjectId": "325e4f19c5294b69a36f11265d8641b9",
"m_Group": {
"m_Id": ""
},
"m_Name": "Position",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -1069.0,
"y": -319.0,
"width": 206.0,
"height": 131.0
}
},
"m_Slots": [
{
"m_Id": "a5c2335391b24eba8684558f71ed4c27"
}
],
"synonyms": [
"location"
],
"m_Precision": 1,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 2,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_Space": 0,
"m_PositionSource": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.RotateAboutAxisNode",
"m_ObjectId": "35fc4044314442a584349e8789db0747",
"m_Group": {
"m_Id": ""
},
"m_Name": "Rotate About Axis",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -353.0,
"y": -177.0,
"width": 164.0,
"height": 177.0
}
},
"m_Slots": [
{
"m_Id": "a0c81fc904994163b5814cfe3f4c0c9e"
},
{
"m_Id": "7216b51f10244b729a192c02fb53d251"
},
{
"m_Id": "21821b9616e445458615181a9341aa56"
},
{
"m_Id": "906e24db9e29473a9d73e2cce946828d"
}
],
"synonyms": [
"pivot"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_Unit": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "35fcd8a35e934a62b88bc5cab307c568",
"m_Id": 4,
"m_DisplayName": "R",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "R",
"m_StageCapability": 2,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 2,
"m_Type": "UnityEditor.ShaderGraph.TransformNode",
"m_ObjectId": "37375e12bf3c41eb91c35e09b4e7946f",
"m_Group": {
"m_Id": ""
},
"m_Name": "Transform",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -882.0,
"y": -28.0,
"width": 212.0,
"height": 157.0
}
},
"m_Slots": [
{
"m_Id": "e5089fcc9fda4f17988359022363b0bd"
},
{
"m_Id": "5efb1da245c94867ab8d5324d594c99d"
}
],
"synonyms": [
"world",
"tangent",
"object",
"view",
"screen",
"convert"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_Conversion": {
"from": 2,
"to": 0
},
"m_ConversionType": 1,
"m_Normalize": true
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.CategoryData",
"m_ObjectId": "4297c401299a4f48a401d53ed3a76471",
"m_Name": "",
"m_ChildObjectList": [
{
"m_Id": "85672431213548ca8a0ef8bc5f543d8c"
}
]
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "46541f5acf8a49fea801a78356bc6585",
"m_Id": 1,
"m_DisplayName": "Axis",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Axis",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 1.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicValueMaterialSlot",
"m_ObjectId": "4bc7038d56c84ff6aea7a85b048ecca1",
"m_Id": 0,
"m_DisplayName": "A",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "A",
"m_StageCapability": 3,
"m_Value": {
"e00": 0.0,
"e01": 0.0,
"e02": 0.0,
"e03": 0.0,
"e10": 0.0,
"e11": 0.0,
"e12": 0.0,
"e13": 0.0,
"e20": 0.0,
"e21": 0.0,
"e22": 0.0,
"e23": 0.0,
"e30": 0.0,
"e31": 0.0,
"e32": 0.0,
"e33": 0.0
},
"m_DefaultValue": {
"e00": 1.0,
"e01": 0.0,
"e02": 0.0,
"e03": 0.0,
"e10": 0.0,
"e11": 1.0,
"e12": 0.0,
"e13": 0.0,
"e20": 0.0,
"e21": 0.0,
"e22": 1.0,
"e23": 0.0,
"e30": 0.0,
"e31": 0.0,
"e32": 0.0,
"e33": 1.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "4c120954e49d44c6a046fa5adbb29cfb",
"m_Id": 5,
"m_DisplayName": "G",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "G",
"m_StageCapability": 2,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "53e7f127466a428b81bb735c2cc7d722",
"m_Id": 3,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Texture2DInputMaterialSlot",
"m_ObjectId": "58dadada812e41ecac4e82c662e3808b",
"m_Id": 1,
"m_DisplayName": "Texture",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Texture",
"m_StageCapability": 3,
"m_BareResource": false,
"m_Texture": {
"m_SerializedTexture": "{\"texture\":{\"instanceID\":0}}",
"m_Guid": ""
},
"m_DefaultType": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.ColorRGBMaterialSlot",
"m_ObjectId": "597474c07860476ebfc4d50be1b31f22",
"m_Id": 0,
"m_DisplayName": "Base Color",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "BaseColor",
"m_StageCapability": 2,
"m_Value": {
"x": 0.5,
"y": 0.5,
"z": 0.5
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": [],
"m_ColorMode": 0,
"m_DefaultColor": {
"r": 0.5,
"g": 0.5,
"b": 0.5,
"a": 1.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "59a801a209f04a6c9cd225e5bdc83c6b",
"m_Id": 2,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.AddNode",
"m_ObjectId": "5a76b4302dec45ddb2190ecc57c281d9",
"m_Group": {
"m_Id": ""
},
"m_Name": "Add",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -679.0,
"y": -319.0,
"width": 130.0,
"height": 118.0
}
},
"m_Slots": [
{
"m_Id": "92890b194a434145a91ca47938554b36"
},
{
"m_Id": "ac9359885b1e49aca8d794c8f6a0c5a5"
},
{
"m_Id": "59a801a209f04a6c9cd225e5bdc83c6b"
}
],
"synonyms": [
"addition",
"sum",
"plus"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "5ea464bc9f65451ba987890d6958ebbf",
"m_Id": 2,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "5efb1da245c94867ab8d5324d594c99d",
"m_Id": 1,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.BlockNode",
"m_ObjectId": "635f8317c1d6444c963b9d6e621b45b9",
"m_Group": {
"m_Id": ""
},
"m_Name": "VertexDescription.Position",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": 0.0,
"y": 0.0,
"width": 0.0,
"height": 0.0
}
},
"m_Slots": [
{
"m_Id": "deab0ef59ea843108483c8287cdc51d0"
}
],
"synonyms": [],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_SerializedDescriptor": "VertexDescription.Position"
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.SampleTexture2DNode",
"m_ObjectId": "6404d7bbf8624faf931ba1471844502d",
"m_Group": {
"m_Id": ""
},
"m_Name": "Sample Texture 2D",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -372.00006103515627,
"y": 537.0000610351563,
"width": 183.00003051757813,
"height": 251.0
}
},
"m_Slots": [
{
"m_Id": "ed1ade71b4d24ff2a85eaba521accd74"
},
{
"m_Id": "35fcd8a35e934a62b88bc5cab307c568"
},
{
"m_Id": "4c120954e49d44c6a046fa5adbb29cfb"
},
{
"m_Id": "2b00144db2ef47df8765e2d9ec197ab4"
},
{
"m_Id": "e9114e90211c42a4a483a6ef1c3010a3"
},
{
"m_Id": "58dadada812e41ecac4e82c662e3808b"
},
{
"m_Id": "96a3b4d91bf34ebd93708df05488bda7"
},
{
"m_Id": "faf7b6f99c4b45e0bd4c1177b132b340"
}
],
"synonyms": [
"tex2d"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_TextureType": 0,
"m_NormalMapSpace": 0,
"m_EnableGlobalMipBias": true,
"m_MipSamplingMode": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.BlockNode",
"m_ObjectId": "6e737174c3bc48a893525e11d8b94eb6",
"m_Group": {
"m_Id": ""
},
"m_Name": "VertexDescription.Normal",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": 0.0,
"y": 0.0,
"width": 0.0,
"height": 0.0
}
},
"m_Slots": [
{
"m_Id": "9121028c3d77477eaaf73fb4f086e2fa"
}
],
"synonyms": [],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_SerializedDescriptor": "VertexDescription.Normal"
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "7216b51f10244b729a192c02fb53d251",
"m_Id": 1,
"m_DisplayName": "Axis",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Axis",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 1.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "73db6d308de348e69080623523c9292a",
"m_Id": 0,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 1.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicValueMaterialSlot",
"m_ObjectId": "7ce3ac7090b241ca988dd8882bfb7947",
"m_Id": 1,
"m_DisplayName": "B",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "B",
"m_StageCapability": 3,
"m_Value": {
"e00": 2.0,
"e01": 2.0,
"e02": 2.0,
"e03": 2.0,
"e10": 2.0,
"e11": 2.0,
"e12": 2.0,
"e13": 2.0,
"e20": 2.0,
"e21": 2.0,
"e22": 2.0,
"e23": 2.0,
"e30": 2.0,
"e31": 2.0,
"e32": 2.0,
"e33": 2.0
},
"m_DefaultValue": {
"e00": 1.0,
"e01": 0.0,
"e02": 0.0,
"e03": 0.0,
"e10": 0.0,
"e11": 1.0,
"e12": 0.0,
"e13": 0.0,
"e20": 0.0,
"e21": 0.0,
"e22": 1.0,
"e23": 0.0,
"e30": 0.0,
"e31": 0.0,
"e32": 0.0,
"e33": 1.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "807fca3843a848d4bf68ecd40375fe7b",
"m_Id": 1,
"m_DisplayName": "Scale",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Scale",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "826cf851eb2543beb44bd96eecceb201",
"m_Id": 0,
"m_DisplayName": "Position",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Position",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "835e2be9954a4ec284e3a00899f98e0f",
"m_Id": 4,
"m_DisplayName": "Bounds Size",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Bounds Size",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Internal.Texture2DShaderProperty",
"m_ObjectId": "85672431213548ca8a0ef8bc5f543d8c",
"m_Guid": {
"m_GuidSerialized": "d2dff728-23ea-4e74-bead-a71cf83c7544"
},
"m_Name": "Color",
"m_DefaultRefNameVersion": 1,
"m_RefNameGeneratedByDisplayName": "Color",
"m_DefaultReferenceName": "_Color",
"m_OverrideReferenceName": "",
"m_GeneratePropertyBlock": true,
"m_UseCustomSlotLabel": false,
"m_CustomSlotLabel": "",
"m_DismissedVersion": 0,
"m_Precision": 0,
"overrideHLSLDeclaration": false,
"hlslDeclarationOverride": 0,
"m_Hidden": false,
"m_Value": {
"m_SerializedTexture": "{\"texture\":{\"instanceID\":0}}",
"m_Guid": ""
},
"isMainTexture": false,
"useTilingAndOffset": false,
"m_Modifiable": true,
"m_DefaultType": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Texture2DMaterialSlot",
"m_ObjectId": "8646b417f10347659a9a484473211a50",
"m_Id": 0,
"m_DisplayName": "Color",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_BareResource": false
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "8a6a45a286a54da6948c21d7f57e172c",
"m_Id": 0,
"m_DisplayName": "Alpha",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Alpha",
"m_StageCapability": 2,
"m_Value": 1.0,
"m_DefaultValue": 1.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "906e24db9e29473a9d73e2cce946828d",
"m_Id": 3,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.NormalMaterialSlot",
"m_ObjectId": "9121028c3d77477eaaf73fb4f086e2fa",
"m_Id": 0,
"m_DisplayName": "Normal",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Normal",
"m_StageCapability": 1,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": [],
"m_Space": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "92890b194a434145a91ca47938554b36",
"m_Id": 0,
"m_DisplayName": "A",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "A",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.CameraNode",
"m_ObjectId": "92c17bcc8b8c425c9582a5c1a1fe81e8",
"m_Group": {
"m_Id": ""
},
"m_Name": "Camera",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -1038.0,
"y": -28.0,
"width": 123.0,
"height": 245.0
}
},
"m_Slots": [
{
"m_Id": "826cf851eb2543beb44bd96eecceb201"
},
{
"m_Id": "bc88e557ccf4407b93a2536b512f4e3c"
},
{
"m_Id": "2b0e6acb90c543a5b15de86a021447af"
},
{
"m_Id": "d140504a1d4845c4b26d679530527aa3"
},
{
"m_Id": "02ffabbb5d2540c9978d43fe9bced66e"
},
{
"m_Id": "16afa4add64447f799abb5bd6004fb55"
},
{
"m_Id": "e729fee4b268475f992824482ea4747d"
},
{
"m_Id": "e2bdfd6f3ae4408391020d3d82437d5a"
}
],
"synonyms": [
"position",
"direction",
"orthographic",
"near plane",
"far plane",
"width",
"height"
],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.UVMaterialSlot",
"m_ObjectId": "96a3b4d91bf34ebd93708df05488bda7",
"m_Id": 2,
"m_DisplayName": "UV",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "UV",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0
},
"m_Labels": [],
"m_Channel": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "a0c81fc904994163b5814cfe3f4c0c9e",
"m_Id": 0,
"m_DisplayName": "In",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "In",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "a5c2335391b24eba8684558f71ed4c27",
"m_Id": 0,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "ac9359885b1e49aca8d794c8f6a0c5a5",
"m_Id": 1,
"m_DisplayName": "B",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "B",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.5,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "b2be4eb8902e423dac8fc9557eae894b",
"m_Id": 3,
"m_DisplayName": "B",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "B",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "bc88e557ccf4407b93a2536b512f4e3c",
"m_Id": 1,
"m_DisplayName": "Direction",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Direction",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Arctangent2Node",
"m_ObjectId": "bdc0ea7eb9cb447d8dd08fcfbcd34555",
"m_Group": {
"m_Id": ""
},
"m_Name": "Arctangent2",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -518.0,
"y": -28.0,
"width": 126.0,
"height": 118.0
}
},
"m_Slots": [
{
"m_Id": "f4d09c507d224a19b74f7bf633725fd1"
},
{
"m_Id": "c494607044db436eba18058df443f3d0"
},
{
"m_Id": "5ea464bc9f65451ba987890d6958ebbf"
}
],
"synonyms": [
"atan2"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "c494607044db436eba18058df443f3d0",
"m_Id": 1,
"m_DisplayName": "B",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "B",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 1,
"m_Type": "UnityEditor.Rendering.Universal.ShaderGraph.UniversalTarget",
"m_ObjectId": "c548ef7607014e0da7a8e20ba3e418e9",
"m_Datas": [],
"m_ActiveSubTarget": {
"m_Id": "081930db40d3417eaa49d6e6df667383"
},
"m_AllowMaterialOverride": false,
"m_SurfaceType": 1,
"m_ZTestMode": 4,
"m_ZWriteControl": 0,
"m_AlphaMode": 0,
"m_RenderFace": 2,
"m_AlphaClip": false,
"m_CastShadows": false,
"m_ReceiveShadows": true,
"m_DisableTint": false,
"m_AdditionalMotionVectorMode": 0,
"m_AlembicMotionVectors": false,
"m_SupportsLODCrossFade": false,
"m_CustomEditorGUI": "",
"m_SupportVFX": false
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicValueMaterialSlot",
"m_ObjectId": "c757e87eb2644e24af9f6585b74fa524",
"m_Id": 2,
"m_DisplayName": "Out",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Out",
"m_StageCapability": 3,
"m_Value": {
"e00": 0.0,
"e01": 0.0,
"e02": 0.0,
"e03": 0.0,
"e10": 0.0,
"e11": 0.0,
"e12": 0.0,
"e13": 0.0,
"e20": 0.0,
"e21": 0.0,
"e22": 0.0,
"e23": 0.0,
"e30": 0.0,
"e31": 0.0,
"e32": 0.0,
"e33": 0.0
},
"m_DefaultValue": {
"e00": 1.0,
"e01": 0.0,
"e02": 0.0,
"e03": 0.0,
"e10": 0.0,
"e11": 1.0,
"e12": 0.0,
"e13": 0.0,
"e20": 0.0,
"e21": 0.0,
"e22": 1.0,
"e23": 0.0,
"e30": 0.0,
"e31": 0.0,
"e32": 0.0,
"e33": 1.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "ca2f6195da984047a45d29dd06c85252",
"m_Id": 3,
"m_DisplayName": "World Bounds Max",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "World Bounds Max",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.PropertyNode",
"m_ObjectId": "cf8ac88182a54394afb4615ded88792e",
"m_Group": {
"m_Id": ""
},
"m_Name": "Property",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -528.0000610351563,
"y": 546.0000610351563,
"width": 127.0,
"height": 34.0
}
},
"m_Slots": [
{
"m_Id": "8646b417f10347659a9a484473211a50"
}
],
"synonyms": [],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_Property": {
"m_Id": "85672431213548ca8a0ef8bc5f543d8c"
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "d140504a1d4845c4b26d679530527aa3",
"m_Id": 3,
"m_DisplayName": "Near Plane",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Near Plane",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.RotateAboutAxisNode",
"m_ObjectId": "d31479c4d4c64b049755104be6939c44",
"m_Group": {
"m_Id": ""
},
"m_Name": "Rotate About Axis",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -353.0,
"y": 41.0,
"width": 164.0,
"height": 177.0
}
},
"m_Slots": [
{
"m_Id": "11c6a4fd998645218cee336bbfcb2edc"
},
{
"m_Id": "46541f5acf8a49fea801a78356bc6585"
},
{
"m_Id": "efc585a05a5247d08bcff0cddff0a175"
},
{
"m_Id": "53e7f127466a428b81bb735c2cc7d722"
}
],
"synonyms": [
"pivot"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_Unit": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "d93c661cb8f243989ae22262b9cfef8b",
"m_Id": 2,
"m_DisplayName": "G",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "G",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.PositionMaterialSlot",
"m_ObjectId": "deab0ef59ea843108483c8287cdc51d0",
"m_Id": 0,
"m_DisplayName": "Position",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Position",
"m_StageCapability": 1,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": [],
"m_Space": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.BlockNode",
"m_ObjectId": "e01343c4cdb845dcb252212877f70ee4",
"m_Group": {
"m_Id": ""
},
"m_Name": "SurfaceDescription.Alpha",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": 0.0,
"y": 0.0,
"width": 0.0,
"height": 0.0
}
},
"m_Slots": [
{
"m_Id": "8a6a45a286a54da6948c21d7f57e172c"
}
],
"synonyms": [],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
},
"m_SerializedDescriptor": "SurfaceDescription.Alpha"
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "e2bdfd6f3ae4408391020d3d82437d5a",
"m_Id": 7,
"m_DisplayName": "Height",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Height",
"m_StageCapability": 3,
"m_Value": 1.0,
"m_DefaultValue": 1.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.SplitNode",
"m_ObjectId": "e32470a4c1ba4209826e24682298701c",
"m_Group": {
"m_Id": ""
},
"m_Name": "Split",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -669.0,
"y": -28.0,
"width": 120.0,
"height": 149.0
}
},
"m_Slots": [
{
"m_Id": "17234cae634b4599bc55b9e1f568a9e0"
},
{
"m_Id": "f4e346df623c4eb28f34f7e4a541de3a"
},
{
"m_Id": "d93c661cb8f243989ae22262b9cfef8b"
},
{
"m_Id": "b2be4eb8902e423dac8fc9557eae894b"
},
{
"m_Id": "2da8c8085d9b4bcc8ddcfb7e64076d8c"
}
],
"synonyms": [
"separate"
],
"m_Precision": 0,
"m_PreviewExpanded": true,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "e4341a2a112347e89e6a8a1a1f722075",
"m_Id": 0,
"m_DisplayName": "Position",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Position",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector3MaterialSlot",
"m_ObjectId": "e5089fcc9fda4f17988359022363b0bd",
"m_Id": 0,
"m_DisplayName": "In",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "In",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "e729fee4b268475f992824482ea4747d",
"m_Id": 6,
"m_DisplayName": "Width",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "Width",
"m_StageCapability": 3,
"m_Value": 1.0,
"m_DefaultValue": 1.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "e9114e90211c42a4a483a6ef1c3010a3",
"m_Id": 7,
"m_DisplayName": "A",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "A",
"m_StageCapability": 2,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.MultiplyNode",
"m_ObjectId": "eb63323c6b5d49feacc5978986facc6f",
"m_Group": {
"m_Id": ""
},
"m_Name": "Multiply",
"m_DrawState": {
"m_Expanded": true,
"m_Position": {
"serializedVersion": "2",
"x": -518.0,
"y": -277.0,
"width": 130.0,
"height": 118.0
}
},
"m_Slots": [
{
"m_Id": "4bc7038d56c84ff6aea7a85b048ecca1"
},
{
"m_Id": "7ce3ac7090b241ca988dd8882bfb7947"
},
{
"m_Id": "c757e87eb2644e24af9f6585b74fa524"
}
],
"synonyms": [
"multiplication",
"times",
"x"
],
"m_Precision": 0,
"m_PreviewExpanded": false,
"m_DismissedVersion": 0,
"m_PreviewMode": 0,
"m_CustomColors": {
"m_SerializableColors": []
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector4MaterialSlot",
"m_ObjectId": "ed1ade71b4d24ff2a85eaba521accd74",
"m_Id": 0,
"m_DisplayName": "RGBA",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "RGBA",
"m_StageCapability": 2,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.TangentMaterialSlot",
"m_ObjectId": "ef119d9737b248aab2997c014c8e18bc",
"m_Id": 0,
"m_DisplayName": "Tangent",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Tangent",
"m_StageCapability": 1,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0
},
"m_Labels": [],
"m_Space": 0
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "efc585a05a5247d08bcff0cddff0a175",
"m_Id": 2,
"m_DisplayName": "Rotation",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Rotation",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.DynamicVectorMaterialSlot",
"m_ObjectId": "f4d09c507d224a19b74f7bf633725fd1",
"m_Id": 0,
"m_DisplayName": "A",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "A",
"m_StageCapability": 3,
"m_Value": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
},
"m_DefaultValue": {
"x": 0.0,
"y": 0.0,
"z": 0.0,
"w": 0.0
}
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.Vector1MaterialSlot",
"m_ObjectId": "f4e346df623c4eb28f34f7e4a541de3a",
"m_Id": 1,
"m_DisplayName": "R",
"m_SlotType": 1,
"m_Hidden": false,
"m_ShaderOutputName": "R",
"m_StageCapability": 3,
"m_Value": 0.0,
"m_DefaultValue": 0.0,
"m_Labels": []
}
{
"m_SGVersion": 0,
"m_Type": "UnityEditor.ShaderGraph.SamplerStateMaterialSlot",
"m_ObjectId": "faf7b6f99c4b45e0bd4c1177b132b340",
"m_Id": 3,
"m_DisplayName": "Sampler",
"m_SlotType": 0,
"m_Hidden": false,
"m_ShaderOutputName": "Sampler",
"m_StageCapability": 3,
"m_BareResource": false
}
I need to use a job for this, so I can’t do regular mono behaviors. Here’s an example, that does not work.
[BurstCompile]
public partial struct SpriteBillboardJob : IJobEntity
{
public float3 CameraLocation;
public quaternion CameraRotation;
[BurstCompile]
private void Execute(ref LocalToWorld localToWorld, ref LocalTransform localTransform, SpriteBillboardTag spt)
{
localTransform.Rotation = Quaternion.FromToRotation(localTransform.Up(), localToWorld.Up);
}
}
Wow! Thanks Andrew, you’re an absolute god!! I didn’t look into the shader solution yet, but I’ll definitely look into that since I’ve heard that it’s a lot performant for this kind of feature.
Wanted to note out that, I had to disable the WoldSystemFilter(s) for some reason. Might be that my game project file is wonky, but it’s alright for now!
Thanks again, I’ve been at this for weeks and couldn’t figure out transform matrix updating
Thanks for the third time!!
Good call and your project is fine. This particular WorldSystemFilter attribute setup makes this system run both in and out of play mode. This is the usual one:
[WorldSystemFilter( WorldSystemFilterFlags.Default | WorldSystemFilterFlags.Editor )]
And this is for Netcode-for-ECS projects:
[WorldSystemFilter( WorldSystemFilterFlags.ClientSimulation | WorldSystemFilterFlags.Editor )]
So my bad as I totally forgot to mention it.
Oh right yeah, I remember seeing something about the
– OksamiesNetcode-for-ECSfilters in this video: https://www.youtube.com/watch?v=8efRGtRCGJ0 I'll probably need that way later in my project, but good to know before hand. Thanks for clearing that up!
